IP Cam Fusion Cube. 1MP, 720P, HD Resolution

CCTV IP Camera Factory

IP Cam Fusion Cube

720P

Motion

Detection

Plug &

Play

Tilt

Colors available:

Specifications - 1 Megapixel P2P IP camera

Image Sensor	Sensor	High Definition Color CMOS Sensor
	Display Resolution	1280 x 720 (1Megapixels)
	Min. Illumination	0 Lux (With IR Illuminator)
	IR Cut	Yes

Lens	focal length	f:2.8mm
	Aperture	F:2.4
	Angle of View	105°

Video	Image Compression	H.264
	Image Frame Rate	30fps maxmium, downward adjustable
	Resolution	720P(1280 x 720), VGA(640 x 480), QVGA(320 x 240)
	Image adjustment	The hue, brightness, contrast, saturation, sharpness are adjustable
	Flip image	Flip and mirror
	Infrared mode	Automatic or manual
	Pan/Tilt Angle	Vertical: 120°
	Night visibility	11pcs IR-LEDs, night vision range up to 8 metres

Audio	Input/Output	Supports two-way audio P2P function
		Built-in Mic & Speaker

	Audio Compression	G.726

Network	Wireless Standard	IEEE802.11b/g/n
	Wireless Security	WEP, WPA, WPA2
	WPS	Supports WPS one button push wireless connection
	WPS	Supports WPS one button push wireless connection
	Soft AP	Supports Soft AP to configure

System Requirements	Operating System	Microsoft Windows 2000/XP, Vista, 7
		iOS, Android
	Browser	Microsoft IE6 and above version or compatible browser
		Mozilla Firefox
		Google Chrome
		Apple Safari

Other Features	Micro SD / TF slot	Yes. Max 32GB
	Motion Detection	Alarm via E-Mail, upload alarm snapshot to FTP
	Reset	Reset button is available

Power	Power Supply	DC 5V/2.0A
Power	Power Consumption	3 Watts (Max.)

Physical	Dimension(LxWxH)	117(L)114(W)129(H) mm
	Gross Weight	680.7g
	Net Weight	350g

Environment	Operating Temperature	0° ~ 40°C (32°F ~ 104°F)
	Operating Humidity	20% ~ 85% non-condensing
	Storage Temperature	-10°C ~ 60° (14°F ~ 140°F)
	Storage Humidity	0% ~ 90% non-condensing

Certification	CE, FCC, RoHS

Warranty	Limited 2-year warranty

Optional	WPS
	P2P
	Audio Cable
